Name: Rivers and streams

Display Field: GNIS_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN STYLE="font-size:12pt">The National Hydrography Dataset (NHD) is a feature-based database that interconnects and uniquely identifies the stream segments or reaches that make up the nation's surface water drainage system. NHD data was originally developed at 1:100,000-scale and exists at that scale for the whole country. This high-resolution NHD, generally developed at 1:24,000/1:12,000 scale, adds detail to the original 1:100,000-scale NHD. (Data for Alaska, Puerto Rico and the Virgin Islands was developed at high-resolution, not 1:100,000 scale.) Local resolution NHD is being developed where partners and data exist. The NHD contains reach codes for networked features, flow direction, names, and centerline representations for areal water bodies. Reaches are also defined on waterbodies and the approximate shorelines of the Great Lakes, the Atlantic and Pacific Oceans and the Gulf of Mexico. The NHD also incorporates the National Spatial Data Infrastructure framework criteria established by the Federal Geographic Data Committee.</SPAN></P><P><SPAN STYLE="font-size:12pt">Update October 2018</SPAN></P></DIV></DIV></DIV>

Service Item Id: f40c204c87de4964ad50571be9b93839

Copyright Text: USGS National Hydrological Dataset (NHD) and Digital Line Graphs (DLG) WVGISTC

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 750000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -9386673.9964
YMin: 4331468.177500002
XMax: -8580649.9886
YMax: 5008816.124799997
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [115, 223, 255, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 25
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 92, 230, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 7
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 750000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• PERMANENT_ ( type: esriFieldTypeString, alias: PERMANENT_, length: 40 )
• FDATE ( type: esriFieldTypeDate, alias: FDATE, length: 8 )
• RESOLUTION ( type: esriFieldTypeDouble, alias: RESOLUTION )
• GNIS_ID ( type: esriFieldTypeString, alias: GNIS_ID, length: 10 )
• GNIS_NAME ( type: esriFieldTypeString, alias: GNIS_NAME, length: 65 )
• LENGTHKM ( type: esriFieldTypeDouble, alias: LENGTHKM )
• REACHCODE ( type: esriFieldTypeString, alias: REACHCODE, length: 14 )
• FLOWDIR ( type: esriFieldTypeDouble, alias: FLOWDIR )
• WBAREA_PER ( type: esriFieldTypeString, alias: WBAREA_PER, length: 40 )
• FTYPE ( type: esriFieldTypeDouble, alias: FTYPE )
• FCODE ( type: esriFieldTypeDouble, alias: FCODE )
• SHAPE_LENG ( type: esriFieldTypeDouble, alias: SHAPE_LENG )
• MAINPATH ( type: esriFieldTypeDouble, alias: MAINPATH )
• INNETWORK ( type: esriFieldTypeDouble, alias: INNETWORK )
• VISIBILITY ( type: esriFieldTypeDouble, alias: VISIBILITY )
• Shape_Le_1 ( type: esriFieldTypeDouble, alias: Shape_Le_1 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Generate Renderer   Return Updates
